The R-Tech PLASMA 50CNC is a member of our field acclaimed family of welding products. Premium
features include:
1. Inverter power source - more efficient to operate, provides smoother weld characteristics.
2. CNC Interface giving Start, Arc Success & voltage reading for THC systems
3. NON-HF Pilot Arc starting – No local interference compared to HF start machines
4. Pilot arc restart - ideal for cutting mesh etc
5. Digital amp meter
6. Quick fitting torch for easy torch fitment/replacement
7. Long life -Low cost torch consumables
8. 60% Duty cycle at 50 Amps @ 40
Recommended Processes
The R-Tech PLASMA 50CNC is recommended for the plasma cutting processes within its output capacity of
50 Amps DC
Equipment Limitations
The R-Tech PLASMA 50CNC is protected from overloads beyond the output ratings and duty cycle as per machine
specifications with thermostat protection of the output coils and rectifiers and is rated at 50 Amps at 60% duty cycle
on a ten minute basis. If the duty cycle is exceeded a thermal protector will shut machine off until the machine cools.
Model R-Tech P50CNC
Input Power
Fuse rating
Rated output current
Current adjustment range
No load voltage
Duty cycle @ 40c
Starting Mode
Air pressure
Max Cutting Thickness – Hand Torch – Clean Cut – Mild Steel
Max Cutting Thickness – Hand Torch – Severance Cut – Mild Steel
Max Cutting Thickness – Machine Torch Piercing – Clean Cut – Mild Steel
Air post flow
Dimensions
Weight
Introduction
O
C

Technical Specifications

220 / 240V 50/60Hz
32 Amps
50 Amps
20 – 50 Amps
200V
60 %
Pilot Arc – Cartridge start NON HF
70 PSI
18mm
24mm
12mm
- 25s
390 x 190 x 290
18KG
