Turn the input power OFF at the mains switch & fuse box before working on this equipment.
Have a qualified electrician install & service this equipment.
Allow machine to sit for 5 minutes minimum to allow the power capacitors to discharge before working
inside this equipment. Do not touch electrically live parts
The I-MIG 200 Mig Welder requires a 240V 50/60Hz 1-Phase supply. It requires an 19A supply. It
comes with a 3 metre mains cable attached.
Connect wires according to national coding.
Brown wire – Live
Blue wire – Neutral
Green/Yellow Wire – Earth (Ground)
Connecting to a mains electrical supply
THIS MACHINE IS OF AN INDUSTRIAL SPECIFICATION AND MUST BE FITTED
Failure to connect to correct supply will in-validate your warranty
DO NOT CONNECT TO A 13AMP DOMESTIC PLUG
Connecting to an Engine Driven Generator
If connecting this machine to an engine driven generator please ensure the
Minimum Generator KVA Output – 7 KVA continuous
Generator to be fitted with AVR (automatic voltage regulation)
DO NOT USE ON A GENERATOR WITHOUT AVR
Connecting to a generator without the above minimum requirements will in-
7
TO A 20AMP 240V MAINS INPUT
following
validate your warranty.
