R-Tech I-MIG200 Operation Instructions Manual page 11

5. On/Off Power Switch
This turns the I-Mig200 Mig Welder on and off.
6. Wire Speed
This adjusts the wire feed speed from 0-100%
Adjust the wire speed to suit welding voltage (Fig 3.1) and job requirements
When adjusting the wire feed speed a value is shown in the amperage LED (Fig 3.8)
This feature allows you to record this value along with the preset welding voltage for easy
setup to specific job when several different welding jobs are being done
7. Voltage LED Display
This shows the preset welding voltage when no welding is being carried out
When welding this shows the actual welding voltage
This allows the machine to be calibrated to BS if required by your company
8. Amperage LED Display
This shows the preset wire feed speed when no welding is being carried out
When welding this shows the actual welding amperage
This allows the machine to be calibrated to BS if required by your company
9. Warning LED
This warning light will come on under these situations
Duty cycle of machine has been exceeded, the machine will stop working and the fan will
continue to run until machine has cooled down. The light will go off and welding may be
carried out again.
If duty cycle has not been exceeded the warning light comes on to warn of either
low input voltage has been sensed or there is an internal fault with machine
10. Power LED
This lights when machine is switched on
11
Cont....
Side Panel
