Printer drivers and firmware

Parallel interface

USB interface (Windows2000/
XP)
Downloading firmware to
the printer
18
Make sure that the parallel interface is selected in the printers menu for
USER1, that in the PCs BIOS the parallel port is set to ECP and that
the parallel cable meets the IEEE1284 standard.
Make sure that the USB interface is selected in the printers menu for
USER1, that a printer driver has been installed and the printer is defi-
ned as default printer.
To load new firmware to the printer, proceed as follows. As mentioned
before it is important that no other device (printer) is set to the inter-
face you want to use for the download.
Click therefore Start > Control Panel > Printers and Faxes and
check that no printer is set to the port you want to use. E.g. if you want
to use the serial interface RS232 no printer may have connected to the
COM1 port.
Browse to the folder where the firmware files are stored.
1.
Double-click the
Standard Model PB Flash VX.XX.exe file.
2.
On the Memory Writer screen select the interface (in our example
3.
serial port).
Make sure that the settings for port, baudrate, parity bit and stop
4.
bit are correct.
Select IPL FIRMWARE from Download Type.
5.
Click Browse and select the
6.
Click FLASH NOW; the download process starts.
7.
When the download process is finished, the printer performs an initiali-
zation
Repeat step 5 to 7 for the
8.
PBCGXXXX.BIN file.
BL_XXXX.IPL file.
and the
FWXXX.mfw file
