User Guide
Parameter group Parameter
Top of form pos.
Bottom edge
Line width
Left edge
Reference edge
Continuous Print
MENU Media
CONTROL
Impact
Speed
Low noise
1) Only in Epson and IBM emulation
2) Only if MSR-H is installed
3) Only for printer model with second serial interface
Possible settings
0/60
I
10/60
I
60/60
1)
0/60
30/60
1)
80 @ 10 cpi
90 @ 10 cpi
94 @ 10 cpi
10/90"
I
90/90"
Left
Right
Off
On
Cut Sheet
H. Binding
V. Binding
1, 2, 3, 4, 5, 6*, 7, 8
Auto
Normal
High
Off
On
Description
Sets the position of the first printing line. The
factory setting for the first printing position is
* 10/60" (4,23 mm). This is equivalent to the
second line from the top.
* Sets the distance between last printing line
and bottom edge.
* Sets the line length; unit is number of charac-
ters at a character density of 10 cpi.
If 80 is chosen in Olivetti emulation, 90 is used
for the line length instead of 80.
* Sets the left margin; unit is n/90 inch.
* Sets the horizontal leading edge.
Left: the left edge of the character matrix is ali-
gned to the the left edge of the document.
Right: the right edge of the character matrix is
aligned to the right edge of the document.
* Selects the handling of paper when the vertical
position exceeds the form length.
* Specifies the media type.
Select H. Binding if you want to print
passbooks with horizontal binding, V. Binding
for passbooks with vertical binding.
Cut Sheet: 400 cps max
H. Binding: 300 cps max
V. Binding: 300 cps max
Selects the impact strength of the print head
for printing on cut sheets. This ensures that
single or copy paper produces optimum
results.
6: for single-ply paper.
7: for 2- or 3-ply paper
8: for 4-ply paper and above
* Auto: depends on the settings of MEDIA
Normal: 300 cps
High: 400 cps
* Switches the low noise function on and off.
Menu
61
