M a i n
A d v a n c e d
OnBoard I/O Configuration
COM1 Address
COM1 Function Type
COM1 RI PIN Voltage
COM2 Address
COM2 Function Type
COM2 RI Pin Voltage
COM1 Address [3F8/IRQ4]
Options: Disabled, 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3
COM1 Function Type [RS232]
Options: RS232, RS422, RS485
COM1 RI PIN Voltage [Normal]
Options: Normal, 5V, 12V
COM2 Address [2F8/IRQ3]
Options: Disabled, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3
COM2 Function Type [RS232]
Options: RS232, RS422, RS485
COM2 RI Pin Voltage [Normal]
Options: Normal, 5V, 12V
M a i n
A d v a n c e d
OnBoard Peripherals Configuration Settings
USB Controller
USB 2.0 Controller
Audio Controller
Onboard LAN Controller
Onboard LAN OPTROM
USB Controller [Enabled]
Options: Enabled, Disabled
USB 2.0 Controller [Enabled]
Options: Enabled, Disabled
QBOX-1010 User's Manual

Table 6 OnBoard I/O Configuration Settings

BIOS SETUP UTILITY
B o o t
[3F8/IRQ4]
[RS232]
[Normal]
[2F8/IRQ3]
[RS232]
[Normal]
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.

Table 7 OnBoard Peripherals Configuration Settings

BIOS SETUP UTILITY
B o o t
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
C h i p s e t P o w e r
C h i p s e t P o w e r
[Enabled]
[Enabled]
[Enabled]
[Enabled]
[Disabled]
28
Chapter 3
S e c u r i t y E x i t
Allows BIOS to Select Serial
Port1 Base Address.
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
S e c u r i t y E x i t
Options
Disabled
Enabled
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
