Setting up your PC

Connect the monitor, mouse and keyboard
Connecting the monitor
Connect the DVI cable from your display to the DVI port.
To connect a VGA display, you need the DVI to VGA adapter to connect a
display with a VGA connector.
When the system reboots without connecting the DVI, there might be no
image on screen when you insert the DVI cable. Please
pressing <Ctrl>+<Alt>+<F4> simultaneously to show the image on screen.
QBOX-1010 User's Manual
Chapter 2
Getting Started

Figure 4 Connect the DVI cable

NOTE
NOTE
20
Chapter 2
