MIC-IN
The microphone jack is designed to connect the microphone used for video
conferencing, voice narrations, or simple audio recordings.
Audio Out
The stereo headphone jack (3.5mm) is used to connect the system's audio out
signal to amplified speakers or headphones.
Power LED
The power LED will light when the PC is power-on.
HDD LED
The hard disk LED blinks when data is being written into or read from the HDD.
Reset Button
To reset the computer, use the tip of a pen to press the Reset button briefly (for
less than three seconds).
Power Switch
The power switch allows powering ON and OFF the system.
