1. Getting Started

This section describes the features of the GV-Data Capture V3 Series, the inventory of the
items that have supplied with GV-Data Capture, and the software version required for this
application.

1.1 Introduction

The GV-Data Capture V3 Series can interface with POS systems and GV-System to
overlay transaction data on video footage. This allows you to investigate a transaction data
by either live view or playback.
The V3 Series comes in two models: V3 and V3E. The difference between the two models
is the V3E features an Ethernet port, connecting POS systems to GV-System through LAN
or Internet. The features of the V3 Series include:
•
V3E of Ethernet model provides LAN / Internet connection.
•
Supports both serial and parallel POS systems and cash registers.
•
Connects up to 16 POS systems to a single GV-System.
For details on V3 Settings, see Chapter 3, and for details on V3E Settings, see Chapter 4.
POS System (Cash Register) 1
POS System (Cash Register) 16
GV-Data Capture V3
GV-Data Capture V3 Series
GV-Data Capture V3
GV-Data Capture V3 Series
Figure 1
Getting Started
1
GV-System
1
