Setting button. The GV-Data Capture V3E Web interface (see Figure 10) will appear.
6. Click OK to add the POS system to GV-System.

4.2.2.2 Connection over Internet

1. Follow the Steps 1 to 3 in 4.2.1 Fixed IP. The Data Capture Box IP Setting dialog box
appears.
2. Select IP Info. in DDNS Server, and type the domain name registered on the DDNS
Server.
3. In the Device Port field, keep default value 4000. Or modify it to match that of the POS
system (see Figure 22).
4. In the Password field, type default value 1234.
5. If you need to change or view the configurations of the V3E, click Browse Device
Setting. The GV-Data Capture V3E Web interface (see Figure 10) will appear.
6. Click OK to add the POS system to GV-System.
Figure 21
V3E Settings
4
25
