2.2 Baud Rate Setup

To have the POS data transferred to the GV-System via the GV-Data Capture, you need to
set the exact baud rate in each connected device, including the GV-Data Capture and
POS systems.
On the side panel of the GV-Data Capture, there is a Baud Rate Switch. Each number
(from 0 to 7) on the Switch represents a kind of baud rate. Set the baud rate to correspond
to that of the POS system.
Switch Number
0
1
2
3
4
5
6
7
Baud Rate
115200
(default value)
57600
38400
19200
9600
4800
2400
1200
