GeoVision GV-Data Capture V3 User Manual page 22

Installing LocalDDNS Server
To install the LocalDDNS Server in a computer:
1. Insert the Surveillance System Software CD to your computer. It will run automatically
and pop up a window.
2. Select Install GeoVision System.
3. Select GeoVision LocalDDNS Server, and then follow on-screen instructions.
4. Run LocalDDNS.exe.
The program will be minimized to the system tray.
Figure 12
Configuring V3E for the Connection over LAN
After running the LocalDDNS Server, configure the V3E to match your network
requirements.
1. Open an Internet browser, and type the web address: http://192.168.0.100.
The login dialog box (see Figure 9) appears.
2. In the User Name and Password fields, type default value admin and 1234
respectively, and click OK. The GV-Data Capture V3E Web interface (see Figure 10)
appears.
Note: User Name is fixed, but Password is changeable. See 4.3.3 Changing Password.
16
