788T User Guide and Technical Information
Front Panel Descriptions cont.
Stop/Pause Key
19)
Momentarily press and hold this key to
stop recording. In playback mode, a sin-
gle press pauses playback (play-pause),
allowing audio scrubbing with the FF
and REW keys. Another press of the key
enters play-stop mode where the FF and
REW keys select fi les for playback from
the current directory, the fi lename and
time display fl ash to indicate that a new
fi le has been selected. One more press of
the key exits playback mode.
Pressing the STOP key whilst in stop
mode displays the name of the next fi le
to be recorded in the LCD. In the Setup
Menu the STOP key is also used to exit
from any menu, returning to the main
display.

Panel Lock

Press and hold the
ton Lock Screen. Button lock prevents unintentional setting changes and/or record status. The 788T
displays any button lock options currently enabled.
select the soft keys to
activate the appropriate
button lock mode
There are three modes:
• Unlocked – all keys are accessible and operate normally.
• Non-Transport Lock – All front panel controls are locked except the Record, Stop, Play, Rewind
and Fast Forward keys.
• Lock All – All front panel keys are locked except the REC key. The REC key is kept active so
the user can initiate recording after entering this mode and enter cue markers. To stop record-
ing in this mode, you must disengage the panel lock and press the stop key.
8
v. 1.65 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
1 2 3
1 3 5 7
2 4 6 8
13
LCD backlight key then the
4 5
MENU
HDD
14 15
16
Record Key
20)
Press to begin recording. The 788T is
a record-priority device; pressing this
key starts recording and discontinues
all other functions, except fi le opera-
tions. The REC key will illuminate red
when the 788T is actively recording. If
the selected storage media is not ready
to begin recording a new fi le, the REC
key will fl ash red until the recording has
begun. Pressing the REC key during re-
cording can set a cue marker, start a new
fi le, as selected in the Setup Menu.
Record LED
21)
Illuminates red when record mode is
active.
TONE key to bring up the front panel But-
7 8 10
6 9
788T
INPUT PWR
ARM ARM
R C
L D
A E
B F
0
d BFS
REC
IN CF EX
17 18 19
20
11 12
0
d BFS
21
