7. The new track assignments will be visible from the Input Settings Window.
Routing Using the CL-8
From the CL-8 the user can quickly make input to track routing changes to the Left, Right, Aux 1,
and Aux 2 Tracks. See CL-8 controller section for more details.

Routing Using the Setup Menu

Press and hold STOP then press the INPUT key to bring up the following menu. This menu can also
be accessed via the Setup Menu option INPUT: TRACK ROUTING.
Continue to hold down the Stop key then press the
input-to-track routing combinations. These presets are factory set and cannot be changed. The last
three preset selections are CUSTOM ROUTE options. Press the EDIT soft key to enter the custom rout-
ing menu. Custom routing allows any input to be assigned to any track. In the menu, highlighted
input and track combination are displayed in white text. The eight inputs are shown on the left; the
twelve tracks are shown on the right. Tracks can be assigned as pre or post fade, when the given
track is highlighted press the Play key to toggle between pre and post fade assignment.
To assign custom input routings:
1. Press the INPUT key until INPUT TRACK ROUTING is displayed on the LCD display.
selet to move up
and down menu
788T User Guide and Technical Information
INPUT key to cycle through the preset
arrow indicates high-
lighted input is assigned
to highlighted track
highlighted selection indicates
if the input is sent pre or post
fade to the select track
select to exit menu
and apply selected
routing
select to remove
input assignment
29
