788T User Guide and Technical Information
2. Press the EDIT soft button (
3. Using either the Multi-Function Rotary Switch or the up and down arrows, navigate to the desired
input-to-track combinations.
4. When a chosen pairing is highlighted, press either the ASSIGN soft key or the Multi-Function Rotary
Switch to assign the combination. Assigned tracks are noted on the screen by the addition of an arrow
pointing to the record track.
5. Inputs can be assigned to tracks pre or post fade. Press the Play key to toggle between pre and post fade
routing per input.
6. Once a track is assigned, move to the next input-to-track combination desired.
7. To remove an input-to-track combination assignment, navigate to that combination and press the
UNASSIGN (LCD Backlight) soft key or the Multi-Function Rotary Switch.
8. Exit and complete the assignment by pressing the Check Mark (Tone) soft key.
The Input Routing menu will always exit to the main screen. Tracks must be armed in the Track Setup
Menu in order to record.

Track Arming

The 788T will only record armed tracks. Armed tracks are tracks that are record enabled and have ac-
tive inputs routed to them. These are indicated by the blue Track Arm LEDs on the 788T front panel.
Track Enabling is controlled in the Track Setup Menu. At least one track has to be enabled in order
for the 788T to begin recording. Additionally, at least one active input has be assigned to a record
enabled track in order for the track to be recorded. To enable a track for recording perform the fol-
lowing steps.
1. Enter the Track Setup Menu by pressing the INPUT key.
2. Navigate through the Tracks using the Multi-Function Rotary Switch. The Track with the box around it
is the selected track. This is Track G in the above image.
3. The * in front of a given track indicates that the track is record enabled. Tracks that are record enabled
and have at least one active input routed to it are considered armed and will be recorded. Enable/Dis-
able select tracks by pressing in on the Multi-Function Rotary Switch. The above image indicates that
Tracks L, R, A, B, C, D, E, F, G, and H are enabled for recording. Tracks X1 and X2 may have inputs
routed to them, but are not enabled and will not be recorded.
4. Exit the Track Setup Menu by pressing the INPUT key.
When recording higher track counts or higher sampling rates, Sound Devices recommends using hard
drives and high speed UDMA CompactFlash cards.
30
v. 1.65 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
) and scroll to the appropriate input screen.
