CL-8 Views

The CL-8 allows for quick control of input-to-track routing and input settings on each Input. Use the
Alt button to toggle between the Main, Aux Routing, and Input Settings View.

Main View

The Main View is always the fi rst of the CL-8 views to be displayed after startup or initial connection
of the CL-8. From the Main View the following settings are displayed for each input.
• Input Activity
• Left/Right Track Routing
• Aux 1/Aux 2 Track Routing
• Limiter Status
From the Main View, route any active input to Track L or Track R using the A and B buttons respec-
tively. Solo any active input by simultaneously pressing the A and B buttons. Press the ALT button to
move to the Aux Routing View.

Aux Routing View

From the Aux Routing View any input can be routed to Track X1 (Aux 1) or X2 (Aux 2) by pressing
the A and B buttons respectively. While in the Aux Routing View the L, R, Lim, Input Polarity and
High-Pass Filter LED indicators are disabled. The Aux 1 and 2 LEDs will illuminate solid for any in-
put that is currently routed to X1 and X2 tracks. The LED illuminates green when the input is routed
pre-fade to the Aux track. The LED illuminates red when the input is routed post-fade to the Aux
track. Toggle between pre and post fade routing by pressing and holding the A and B buttons for
each input. If the input hasn't been assigned to an Aux track the LED will fl ash. Press the ALT button
to move to the Input Setting View.
788T User Guide and Technical Information
• Input Polarity Status
• High-Pass Filter Status
• Solo (pre fade listen)
• Input Mute
