Left Panel Connectors and Controls

XLR Analog Inputs Channels 1-4
1)
Active-balanced analog microphone- or
line-level input for inputs 1-4 on XLR
connector. Input type is set within the
Input Settings Window. Pin-1 ground,
pin-2 (+), pin-3 (
TA3 Analog Input Channels 5-8
2)
Active-balanced analog microphone-
or-line-level input connector for inputs
5-8. Input type is set within the Input
Settings Window. Pin-1 ground, pin-2
−
(+), pin-3 ( ).

LCD Display Descriptions

Battery/Voltage Level Indicator
1)
Indicates voltage level of the remov-
able battery or external power sources.
If present, external power overrides
battery power. Graphical bar for relative
level and numeric indicator for precise
voltage measurement.
1
−
).
1 2
8
9 10 11
12
788T User Guide and Technical Information
3
2
Headphone Volume
3)
Adjusts the headphone volume. NOTE:
the 788T is capable of producing ear-
damaging levels in headphones. Please
use with caution
5 6
3 4
14 15 16
13
File Name Display
2)
Shows fi le name actively being recorded
or played back. In Playback-Stop mode,
fl ashing fi le name indicates that the
Fast-Forward and Rewind keys can be
used to step through fi les in the current
playback directory.
7
