Available audio sources for headphone monitoring include:
HP Sources
Inputs 1,2
Inputs 3,4
Tracks L,R
Tracks A,B
Tracks C,D
Input 1
Input 2
Input 3
Input 4
Track L,
Track R
Track A
Track B
Track C
Track D
Inputs 1,2 (MS)
Inputs 3,4 (MS)
Tracks L,R (MS)
Tracks A,B (MS)
Tracks C,D (MS)
Inputs 1-4
Inputs 1-6
Tracks LA, RB
Tracks LAC, RBD
Tracks LACE, RBDF
Tracks LACEG, RBDFH
Tracks LACEGX1, RBDFHX2
Tracks LRAB
Tracks LRABCD
Tracks LRABCDEF
Tracks LRABCDEFGH
Tracks LRABCDEFGHX1X2
Tracks LR
Inputs B-format stereo
Tracks B-format stereo
When tracks are monitored in headphones, audio assigned to the tracks is heard in headphones while
Recording. During Playback the recorded track audio is heard in headphones.

Input Solo (PFL)

Inputs are quickly soloed (pre fade listen) in headphones by pressing its corresponding Input Selec-
tor Switch. This will latch on the Input Settings Window and solo the input in the headphone moni-
tor. To exit the Input Settings Window and return to the last headphone monitor program, press the
selected Input Selector Switch again.
If momentary action is desired, press and hold the Input Selector Switch for one second or longer.
If the Input Selector/Solo Switch is held for 5 or more seconds "Hold" will appear on the screen
and the soloed input will remain in the headphone monitor until either another headphone moni-
Stereo monitoring of input pairs. Inputs 1, 3, 5, and 7 are assigned
Inputs 5,6
to left headphone outputs; inputs 2, 4, 6, and 8 are assigned to right
Inputs 7,8
headphone outputs.
Stereo monitoring of track pairs. Tracks L, A, C, E are assigned to left
Tracks E,F
headphone output; tracks R, B, D, and F are assigned to right head-
Tracks G,H
phone output. During playback, will play as track monitor.
Tracks X1,X2
Solo monitoring of selected input. This signal is sent to both sides of
Input 5
the headphones.
Input 6
Input 7
Input 8
Solo monitoring of selected track. This signal is sent to both sides of
Track E
the headphones. During playback, will play as track monitor.
Track F
Track G
Track H
Track X1
Track X2
Stereo monitoring of discrete M (mid) and S (side) input pairs. High-
Inputs 5,6 (MS)
lighted media is source of monitor program.
Inputs 7,8 (MS)
Stereo monitoring of discrete M (mid) and S (side) track pairs.
Tracks E,F (MS)
Highlighted media is source of monitor program. During playback will
Tracks G,H (MS)
function as MS track monitor.
Tracks X1,X2 (MS)
Combinations of summed inputs appear in each ear.
Inputs 1-8
Combinations of summed tracks appear in each ear. Combinations
Tracks LRA
without commas (,) are dual mono and program appears in both left
Tracks LRB
and right headphone monitors.
Tracks LRC
Tracks LRD
Tracks LRE
Tracks LRF
Tracks LRG
Tracks LRH
Tracks LRX1
Tracks LRX2
The built-in SoundField B-format decoder uses three inputs to build a
left/right stereo signal for monitoring.
