Drive Replacement

The internal hard drive can be removed and replaced if the device fails or if a different capacity drive
is needed. The internal hard drive is not intended to be a swappable, deliverable medium. Its multi-
pin connector is not rated for repeated insertion and removal cycles and may be prone to breakage
with repeated cycling.
In typical service conditions Sound Devices recommends hard drive replacement once every three years.
The hard drive is mounted to the bottom-side of the recorder's chassis and is screwdriver accessible.
The drive is "suspended" in the unit with a shock absorbing foam and is attached to the main circuit
board via a "fl ex board". Since the high-density circuitry and tight construction require specifi c
electronics knowledge, Sound Devices strongly recommends drive replacement be performed by a
qualifi ed technician using proper ESD precautions. Drive replacement done by a qualifi ed technician
has no warranty implications.
The internal hard drive is not intended as a swappable exchange medium. The header connector is not
rated for repeated removal and insertion. Only qualifi ed service technician using proper ESD precautions
should perform drive replacement.
788T User Guide and Technical Information
788T with bottom panel
removed showing hard
drive mounting location
69
