D Rapid charging with the BC-121N+AD-106
The optonal BC-121N allows up to 6 battery packs to be charged
smultaneously. Chargng perod: Approx. 3 hours (wth BP-232N)
The followng tems are addtonally requred.
• Sx AD-106
charger adapter
• An AC adapter (BC-157) or the DC power cable (OPC-656)
AC adapter
(Purchased
separately)
DC power cable
(OPC-656)
(Connect with the
DC power supply;
13.8 V/at least 7 A)
Transceiver
Battery pack
IMPORTANT!:
Ensure the guide
lobs on the
battery pack are
correctly aligned
with the guide
rails inside the
charger adapter.
Guide rails

BATTERY CHARGING

Turn power OFF
AD-106 charger
adapters are installed
in each slot.
