■ Optional battery chargers

D Rapid charging with the BC-160
The optonal BC-160 provdes rapd chargng of the L-Ion battery
pack. Chargng perod: Approx. 3 hours (wth BP-232N)
The followng tems are addtonally requred:
• An AC adapter (may be suppled dependng on verson) or the DC
power cable (OPC-515L/CP-17L) s addtonally requred.
Optional OPC-515L
(for 13.8 V power
source) or CP-17L
(for 12 V cigarette
lighter socket) can
be used instead of
the AC adapter.
AC adapter
(Not supplied with
some versions.)
IMPORTANT:
Ensure the guide lobs
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
BATTERY CHARGING
Transceiver
Battery pack
Guide rail
5
Turn power OFF
Lobs
