■ Charging the battery pack

D Capacity of the battery pack

ICON
The battery has sufficient capacity.
The battery is exhausted a little.
The battery is nearing exhaustion.
(green)
The battery is almost fully exhausted.
L Immediately charge the battery pack. Otherwise, the icon will soon start
blinking, "LOW BATTERY" will be displayed, and the transceiver will
(red)
automatically turn OFF.
To display the correct battery status
Select the attached battery pack in the following item. (Default: BP-271/BP-272)
([MENU] > SET > Function > Battery Pack Select)
To display the Battery Pack Select dialog every time you attach the battery pack, set the
following item to "ON."
([MENU] > SET > Function > Battery Pack Confirmation)
NOTE:
• Before using the transceiver for the first time, the battery pack must be fully charged for
optimum life and operation.
• BE SURE to turn OFF the transceiver while charging. Otherwise, the attached battery pack
cannot be charged.
• While charging, the charging icon "
• The icon and "Charging...." disappear when the battery pack is fully charged.
• You may not be able to charge:
- Depending on your USB cable or power adapter.
- When using a USB hub or connecting to a low output USB port.
• Charging time may differ, depending on the USB port.
• To use a mobile device or a PC as an external power source, set the following item to "ON"
([MENU] > SET > Function > USB Power Input (Phone, Tablet, PC))
(default).
Turn OFF
CAUTION: BE SURE to attach the battery
pack before connecting the USB cable.
L See the Advanced manual about the optional battery packs and chargers.
BATTERY STATUS
" and "Charging...." are displayed.
Supplied USB cable
(Type-C/Type-A)
To the [USB]
To a USB port
INITIAL SETUP
Power adapter
or external battery
(User supplied)
