Icom IC-F15 Instruction Manual page 29

AD-106 installation
D
The AD-106
charger adapter
or BC-121N before battery chargng.
➥ Connect the AD-106
BC-121N as below, then nstall the AD-106 nto the holder
space of the BC-119N or BC-121N wth the suppled screws.
Plugs
must be nstalled nto the BC-119N
charger adapter
AD-106
BATTERY CHARGING
and the BC-119N/
Connectors
Screws supplied
with the charger
adapter
