Icom IC-F15 Instruction Manual page 41

D About VS-1L
The VS-1L s a VOX/PTT unt for Icom handheld transcevers, and
allows you hands-free operaton.
An optonal headset (HS-94, etc.) s addtonally requred for op-
eraton.
• The VOX (voce operated transmsson) functon starts transmsson
wthout pushng PTT swtch when you speak nto the mcrophone;
then, automatcally returns to receve when you stop speakng.
Features
➥ Straght type head SP/MIC plug equpped
➥ Water resstant constructon
➥ Durable constructon
➥ Equpped wth a PTT swtch and revolvng clp.
MIC/VOX gain adjustment
1 Remove the water protecton cover on the rght sde of the VS-1L.
2 Adjust the MIC/VOX gan wth a thn screw drver. Clockwse ro-
taton ncreases the MIC/VOX gan.
3 Return the protectve cover back to the MIC/VOX gan adjust-
ment hole.
Water protecton cover
vox ptt case
/
VS-1L
Adjustng pot
VOX
PTT
OPTIONS
PTT swtch
