Reference Information
Reference Information, cont'd
Specifications
Control/remote — TPS150
Contact closure ............................ (1) 3.5 mm captive screw connector, 8 pole
Contact closure pin configurations 1 = input 1, 2 = input 2, 3 = input 3,
4 = input 4, 5 = volume up,
6 = volume down, 7 = projector power,
8 = GND
General
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, noncondensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, noncondensing
Rack mount .................................. No, but furniture mountable with an
optional CPM Series faceplate
Enclosure type .............................. Metal
Enclosure dimensions
Faceplate ................... 2.8" H x 2.2" W x 0.1" D
(7.1 cm H x 5.6 cm W x 0.3 cm D)
(four space MAAP)
Device ........................ 2.8" H x 2.2" W x 0.5" D
(7.1 cm H x 5.6 cm W x 1.3 cm D)
(Depth excludes connectors and buttons.)
Product weight ............................. 0.5 lbs (0.3 kg)
Shipping weight ........................... 1 lbs (1 kg)
Vibration ....................................... ISTA 1A in carton
(International Safe Transit Association)
Listings .......................................... ETL (UL1950)
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%
Specifications are subject to change without notice.
A-2
CTP150CM Remote Control Panel • Reference Information
Parts List
Included parts
Description
CTP150CM (black)
CTP150CM (white)
or
8-pole captive screw connector
Tweeker (small screwdriver)
1/16" hex wrench
CTP150 Control Panel Module manual
Connected TPS150 transmission system
Description
TPS150
Mini-AAP mounting options
Wall mounting solutions
Description
CPM101B (one-gang) (black)
CPM101W (one-gang) (white)
CPM102B-1 (two-gang) (black) with cable guards
CPM102W-1 (two gang) (white) with cable guards
CPM102B-2 (two-gang) (black) without cable guards
CPM102W-2 (two-gang) (white) without cable guards 60-583-23
CPM103B-1 (three-gang) (black) with cable guards
CPM103W-1 (three-gang) (white) with cable guards
CPM103B-2 (three-gang) (black) without cable guards 60-583-15
CPM103W-2 (three-gang) (white) without cable guards 60-583-25
CPM104B-1 (four-gang) (black) with cable guards
CPM104W-1 (four-gang) (white) with cable guards
CPM104B-2 (four-gang) (black) without cable guards
CPM104W-2 (four-gang) (white) without cable guards 60-583-27
CTP150CM Remote Control Panel • Reference Information
Part number
60-614-10
60-614-20
10-265-05
Part number
70-369-01
Part number
60-583-11
60-583-21
60-583-12
60-583-22
60-583-13
60-583-14
60-583-24
60-583-16
60-583-26
60-583-17
A-3
