Overview

The QBOX-1000 is a fan-less Box PC with a volume of just 0.6-liter that is ideal for
space critical applications. This embedded hardware platform is designed with
Intel® Atom N270 Processor which provides with excellent performance enabled by
next- generation 45nm Process Technology. The system is supported with Intel®
945GSE / ICH7-M chipset, and DDR2 SO-DIMM up to 2GB. Featured are a 2.5"
SATA hard drive bay, eSATA, Internal Compact Flash Type II slot, GbE, USB 2.0 and
DVI-I. The QBOX-1000 provides high reliability rugged case not only for great
protection from EMI, cold and heat, but also integrated with passive cooling design
for quiet fan-less operation such as Digital Signage, Gaming, Transportation,
Surveillance, Automation and Thin Client.
Checklist
QBOX-1000
Power Adapter
Power Cord
Driver CD
Quick installation Guide
Optional VESA Mounting Kit (with 4x M4X6 flat head screws)
Optional wireless LAN module
Features
Fan-less Design and 0.6-Liter Compact Sized
Intel® Atom Processor N270
Intel® 945GSE + ICH7-M
Support DDR2 533 SODIMM up to 2GB
Support 1x DVI-I, 1x GbE, 1x 2.5" SATA HDD, 1x eSATA, 4x USB and Audio
Optional CompactFlash Socket and Wireless Ethernet
