Thank you on your purchase of the ADSL 4 Port Ethernet Router! The ADSL Router provides
you with the high speed multi-user broadband access via ADSL.
The ADSL Router can be connected to any computer(s)/notebook(s) with a 10/100 Base-
T Ethernet Network card. Its Auto MDIX Ethernet Ports allow both Straight and Cross
Ethernet Network cables to be used.
This documentation assumes that your computer/notebook already has an Ethernet Network
card installed.

Minimum System Requirements

• Pentium MMX 233MHz with
®
• Operating system support: OS independent (also depending on the Ethernet Card's
manufacturer's driver support for the Computer/Notebook)
Windows® configurations discussed: Windows® 98 / Windows® 98 Second Edition
/ Windows® Me / Windows® XP / Windows® 2000
• Web Browser support:
Microsoft Internet®
Netscape® Navigator 4.7 (or later versions)
ADSL 4-Port
Ethernet Router
Telephone cable (RJ-11)
1 The telephone extension cable used for this Router is a UL Listed Communication Circuit Accessory, minimum 26AWG.
2 Different countries are bundled with different types of power adapter. The above illustration is only a representative.
3 Depending on your country of purchase, your package may or may not come with a POTS Splitter. The POTS Splitter is required
if you are connecting a Telephone Set to the ADSL Router. Please refer to Step 1.2 - Connecting to the ADSL Line for details. POTS-
Splitter can also be purchased from your dealer.
2

Introduction

Ethernet Network card (installed with TCP/IP Protocol)
Explorer™ 4.0 (or later versions)

ADSL Router Package

Easy Start
1
Power adapter (DC 5V)
POTS Splitter
(optional)
Ethernet Network cable (RJ-45)
2
3
CAT-5 UTP Straight
Router Documentation CD
