ADSL 4 Port Ethernet Router
Easy Start
Version 1.0
•
Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.
•
This product is for use only in UL Listed computers.
Contents
Introduction ....................................................... 2
Minimum System Requirements ........................... 2
ADSL Router Package ......................................... 2
ADSL Router Overview ........................................ 3
Typical ADSL Router Connections ......................... 4
Computer/Notebook ................................ 5
Step 4: Connecting to the Internet ....................... 12
Connection Profile ............................................... 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADSL 4 Port Ethernet Router and is the answer not in the manual?

Questions and answers

Related Manuals for Aztech ADSL 4 Port Ethernet Router

Summary of Contents for Aztech ADSL 4 Port Ethernet Router

  • Page 1: Table Of Contents

    ADSL 4 Port Ethernet Router Easy Start Version 1.0 Contents Introduction ............2 Minimum System Requirements ......2 ADSL Router Package ......... 2 ADSL Router Overview ........3 Typical ADSL Router Connections ......4 Step 1: Connecting the ADSL Router to Your Computer/Notebook ........

  • Page 2: Introduction

    Easy Start Introduction Thank you on your purchase of the ADSL 4 Port Ethernet Router! The ADSL Router provides you with the high speed multi-user broadband access via ADSL. The ADSL Router can be connected to any computer(s)/notebook(s) with a 10/100 Base- T Ethernet Network card.

  • Page 3: Adsl Router Overview

    Easy Start Easy Start Easy Start Easy Start Easy Start ADSL Router Overview Power LED Lights up when Power switch (at the rear) is pressed ON. 10/100 LINK/ACT (1 to 4) Lights up when the Ethernet link is established. Flickers at a slower interval when there is data transfer at 10 Mbps. Flickers at a faster interval when there is data transfer at 100 Mbps.

  • Page 4: Typical Adsl Router Connections

    Easy Start Easy Start Easy Start Easy Start Easy Start Typical ADSL Router Connections Up to 4 PCs Connections ADSL Router Computers or Notebooks with Ethernet Network Cards For More than 4 PCs Connections To connect to more than 4 computers/notebooks, you may further expand one of the Ethernet Ports via an Ethernet Hub/Switch.

  • Page 5: Step 1: Connecting The Adsl Router To Your Computer/Notebook

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 1: Connecting the ADSL Router to Your Computer/Notebook Power off your Computer/Notebook or/and any connected devices before connecting to the ADSL Router! Step 1.1 Connecting to the Power Outlet Back view of the ADSL Router Connect the other end of the...
  • Page 6 Easy Start Easy Start Easy Start Easy Start Easy Start To connect to the ADSL line and a Telephone Set Telephone Wall Socket Back view of the ADSL Router POTS Splitter Connect the Telephone set to the jack labelled TEL or PHONE and the telephone cable to the jack Telephone cable labelled LINE.
  • Page 7 Easy Start Easy Start Easy Start Easy Start Easy Start Step 1.3 Connecting to the Ethernet Connect your computer(s)/notebook(s) to the ADSL Router as illustrated. The following illustration shows the connection of a single computer. Back view of a computer Ethernet Port (All the Ethernet Ports on the ADSL...
  • Page 8 Easy Start Easy Start Easy Start Easy Start Easy Start Step 1.4 Checking Your Connections Please check your connections before proceeding. LINE ETHERNET To your Telephone Wall DC 5V Socket (ADSL line) To your Power Outlet To the Ethernet Port on your Computer(s)/Notebook(s) Step 1.5 Powering Up Power on the Power Outlet that the ADSL Router is connected to.

  • Page 9: Step 2: Configuring Your Ethernet Network Card

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 2: Configuring Your Ethernet Network Card This documentation assumes that your computer/notebook is already installed with an Ethernet Network card. For multiple users connection, please ensure that all your computers/notebooks are configured with the following settings.

  • Page 10: For Windows

    Easy Start Easy Start Easy Start Easy Start Easy Start For Windows 2000 / Windows ® ® Windows® 2000: From your Windows desktop, right-click on the icon My Network Places select Properties. At the Network and Dial-up Connections window, right-click on the Local Area Connection icon and select Properties.

  • Page 11: Step 3: Configuring Your Internet Browser

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 3: Configuring Your Internet Browser Microsoft® Internet Explorer™ (based on IE 5.5) From your Windows desktop, double-click on your Internet Explorer icon launch your Browser. From the Menu, click Tools and select Internet Options...

  • Page 12: Step 4: Connecting To The Internet

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 4: Connecting to the Internet From your Internet Browser, key in http://startmodem/ (or http://192.168.1.1/) at the Address bar and hit <Enter>. An ADSL Web Management interface will be launched. This Web Interface allows you to get connected to the Internet as well as providing the administrative rights to configure your Router's behaviour.

  • Page 13: Appendix A - Configuring Your Adsl Router For A New Connection Profile

    Easy Start Easy Start Easy Start Easy Start Easy Start The default profiles have the DHCP Server and NAT (Network Address Translation) options enabled. If you are not using one of the connection profiles predefined on the ADSL Router, please proceed to Appendix A for instructions on how to create a new connection profile.
  • Page 14 Easy Start Easy Start Easy Start Easy Start Easy Start • For PPPoA routed / PPPoE routed: The PPP Authorization's VPI and VCI values ___________________ User Name ___________________ Password ___________________ Auto DNS (Enable/Disable) ___________________ • Encapsulation method ___________________ (By default, the Encapsulation method used in IPoA is LLC SNAP.
