Step 1:
Power off your Computer/Notebook or/and any connected devices before
connecting to the ADSL Router!
Step 1.1 Connecting to the Power Outlet
Step 1.2 Connecting to the ADSL Line
To connect the ADSL Router to the ADSL line, carried out Step 1.2(a).
To connect the ADSL Router to the ADSL line and a Telephone Set, carried out Step 1.2(b).
(a) To connect to the ADSL line
Connecting the ADSL Router to Your
Computer/Notebook
Back view of the
ADSL Router
Back view of the
ADSL Router
Telephone cable
Easy Start Easy Start Easy Start Easy Start Easy Start
Connect the other end of the
Power Adapter to the Power
Outlet.
Telephone Wall
Socket
5
