Typical ADSL Router Connections

Up to 4 PCs Connections
For More than 4 PCs Connections
To connect to more than 4 computers/notebooks, you may further expand one of the Ethernet
Ports via an Ethernet Hub/Switch. For details on how to connect to the Ethernet Switch/
Hub, please refer to the documentation that comes with the unit.
4
ADSL Router
ADSL Router
Ethernet
Switches/Hubs
Computers or Notebooks with
Ethernet Network Cards
Computers or Notebooks with
Ethernet Network Cards
to Computers/Notebooks with
Ethernet Network Cards
to Computers/Notebooks with
Ethernet Network Cards
