1. The default profiles have the DHCP Server and NAT (Network Address
Translation) options enabled.
2. If you are not using one of the connection profiles predefined on the
ADSL Router, please proceed to
create a new connection profile.
Appendix A
By default, 3 connection profiles have already been predefined on your ADSL Router. The
following shows the basics attributes defined for each of the profiles.
1)
2)
3)
All above 3 profiles have the DHCP Server and NAT (Network Address Translation) options
enabled. The DHCP Server range is 192.168.1.2 to 192.168.1.21 and default LAN IP Address
is 192.168.1.1.
For more details, please refer to the
Management. Click
The following attributes are required for a new connection profile. Check with your ADSL
Service Provider for the values.
•
The ATM/Line Protocol
•
For IPoA routed / RFC 1483 ethernet / RFC 1483 routed:
The addresses for
WAN IP
WAN Subnet Mask
VPI and VCI values
Default WAN Gateway
DNS Relay (Enabled/Disabled)
DNS Server (Primary)
DNS Server (Secondary)
IP Route
Configuring Your ADSL Router for a
New Connection Profile
ATM Protocol = PPPoE routed
VPI/VCI = 0/100
ATM Protocol = PPPoE routed
VPI/VCI = 8/35
ATM Protocol = PPPoE routed
VPI/VCI = 0/35
Expert Mode
Edit
that corresponds to the profile.
Appendix A
> WAN Connections
___________________
___________________
___________________
___________________
___________________
___________________
___________________
__________________
Easy Start Easy Start Easy Start Easy Start Easy Start
for instructions on how to
on the ADSL Web
(to select Enabled)
(optional)
(no routes is defined by default)
13
