Chapter 2

Self-Test and Diagnostics

Following a successful key injection, a double beep indicates that the terminal has automatically
initiated its self-diagnostic routine.
The software and download status of the terminal is displayed during the self-test, which lasts
approximately four seconds. During this time, if the terminal is loaded with the security key, the displays
shown in the following table are typical.
Description
Software: Software name and version.
DLL: Tracks the number of downloads. This is
controlled by Term-Master.
OS: Operating System and version.
Terminal: Terminal ID number.
Installed memory is displayed. The display
indicates one megabyte of memory installed.
A memory page may be in one of the states shown in the following table.
2-4
Table 2-1. Self-test and diagnostics with software loaded
Table 2-2. Memory page states
Status
A
C
F
L
I
U
-
ICE 5000 and 5500 Hardware and Installation Operators Manual
Terminal response
SOFTWARE
DLL
OS
TERMINAL
WAIT SELF TEST
MEMORY PAGE STATUS:
BOOT: XXXX
01: AAAAAAAAAFFFFFF
17: FFFFFFFFFFFFFF
Description
Active: application resident
Corrupt: checksum error
Free
Lost Communication
Inactive
Unknown
No fit: not available for use
IDENTIFICATION
XX_XXXXXX
00
T5KBOOTXXX
NNNNNNNN
