Chapter 2
Self-Test and Diagnostics
Immediately after powering up the terminal, a double beep indicates that the terminal has automatically
initiated its self-diagnostic routine.
The software and download status of the terminal is displayed during the self-test, which lasts
approximately four seconds.
Description
Software: Software name and version.
DLL: Tracks the number of downloads. This is
controlled by Term-Master.
OS: Operating System and version.
Terminal: Terminal ID number.
Installed memory is displayed. The display
indicates one megabyte of memory installed.
A memory page may be in one of the states shown in the following table.
2-4
Table 2-1. Self-test and diagnostics with software loaded
Table 2-2. Memory page states
Status
Description
A
Active: application resident
C
Corrupt: checksum error
F
Free
L
Lost Communication
I
Inactive
U
Unknown
-
No fit: not available for use
ICE 5700 Hardware and Installation Operators Manual
Terminal response
IDENTIFICATION
SOFTWARE
XX_XXXXXX
DLL
OS
T5KBOOTXXX
TERMINAL
NNNNNNNN
WAIT SELF TEST
MEMORY PAGE STATUS:
BOOT: XXXX
01: AAAAAAAAAFFFFFF
17: FFFFFFFFFFFFFF
00
940310-001, rev. A
