3. Ensure that the telephone line cable latches are firmly locked into the jacks on both the ICE 5000
or 5500 terminal and wall receptacle.
W
ARNING
Do not insert the telephone line into the Pin pad port.
940184-003, rev. B
Figure 2-3. ICE 5000 line port
Figure 2-4. ICE 5500 line port
Hypercom Corporation
Installation Procedures
Line port
Line port
2-3
