3. Mount the two terminal transceivers, Hypercom P/N 020123-002, to a vertical surface. Place them
as high as possible in an area that has the best visibility from the areas where the peripheral
devices are used. Separate the transceivers as far as possible from each other while still providing
the required coverage. You may mount the transceivers by using the metal hook or the rubber
suction cups provided. An alternate method is to remove the metal hook and the rubber suction
cups, replacing them with double-sided tape. The terminal transceivers must not be mounted on
or next to metal objects.
4. Insert the male connector of the 12-foot cable from the terminal transceivers into the female
connectors marked Terminal Transceiver 1 or Terminal Transceiver 2 on the terminal transceiver
interface.
If the 12-foot cable is not long enough, it may be extended up to 1000 feet by using any four-
conductor, one-to-one standard telephone extender cable available at various electronic appliance
retail outlets.
You can also have the premises wired for extending the cables. Firms that install telephone cabling
in buildings can perform this task because the wiring is identical to a two-circuit telephone system.
W
ARNING
To avoid damaging the terminal transceiver unit, do not insert the cable connectors from the single unit
adapter or the terminal transceiver into any receptacle designated for use with the premises telephone
system.
