Rear UID LED

The rear UID LED is located at LE11
on the backplane. This LED is used in
conjunction with the rear UID switch to
provide easy identifi cation of a system
that might be in need of service. Refer
to UID Switch on Page 3-31 for more
information.
A
LAN4 LAN3
UID
J1
LAN2
J2
X8DTU-LN4F+
Rev. 2.0
D20
Winbond
BMC
Intel
COMS
Clear
IOH-36D
JBT1
Intel
BIOS
ICH10R
SATA0~5
LE1
FAN3
FPCTRL
T-SGPIO2
User's Manual
VGA1
COM1
LAN2 LAN1
USB0/1
IPMI_LAN
PHY
LAN1
SP1
JBT1
FAN8/CPU1
CPU1
CPU2
3-38
UID LED (LE11)
Status
Color/State OS Status
Blue: On Windows OS Unit Identifi ed
Blue: Linux OS Unit Identifi ed
Blinking
A. UID Rear LED
