Motherboard
X8DTU-LN4F+
Peripheral
Devices •
•
•
•
•
BIOS
•
•
Power
•
Confi g.
•
•
•
PC Health
•
Monitoring
•
•
•
•
•
•
•
System
Management
•
•
•
•
Dimensions
Note: For IPMI Confi guration Instructions, please refer to the Embedded
IPMI Confi guration User's Guide available @ http://www.supermicro.com/
support/manuals/.
User's Manual
USB Devices
Two (2) USB ports on the rear I/O panel (USB 0/1)
One (1) USB connection for front access (USB 6)
One (1) Internal USB connection (USB 7)
Two (2) Type A internal connector (USB 2/3, 4/5)
®
32 Mb SPI AMI BIOS
APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard,
Plug & Play (PnP) and SMBIOS 2.5
ACPI Power Management
Main switch override mechanism
Keyboard Wake-up from Soft-Off
Internal/External modem ring-on
Power-on mode for AC power recovery
CPU Monitoring
CPU1 Vcore, CPU2 Vcore, CPU1 DIMM, CPU2
DIMM, 1.1V, 3.3V, 1.5V, +5V, +12V, 3.3V Standby,
5V Standby, and Vbat.
CPU 6-Phase switching voltage regulator per CPU
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor 2 (TM2) support
Fan Control
Fan status monitoring with fi rmware 4-pin (Pulse
Width Modulation) fan speed control
Low noise fan speed control
PECI (Platform Environment Confi guration Interface)
2.0 support
System resource alert via Supero Doctor III
SuperoDoctor III, Watch Dog, NMI
Chassis Intrusion Header and Detection
14.85" (L) x 12.68" (W) (377.19 mm x 322.07 mm)
2-8
SM Flash BIOS
