Supermicro X8DTU-LN4F+ User Manual page 18

Motherboard
X8DTU-LN4F+
USB 0/1 Back Panel USB 0/1
USB2/3, 4/5, 6 Front Panel Accessible USB Connections
USB 7 Internal USB Connection
UID UID (Universal Identifi er) Switch
UIOP Universal I/O Add-on Card Power (J10) (See the Warning
below.)
VGA 1/2 Backpanel/Front VGA Ports (See Note)
LED Description
D20 BMC Heartbeat LED
LE1 Standby PWR LED
LE11 UID LED
Warnings!
•
To prevent damage to the power supply or motherboard, please use a power
supply that contains a 24-pin and two 8-pin power connectors. Be sure to con-
nect these connectors to the 24-pin (JPW1) and the two 8-pin (JPW2,JPW3)
power connectors on the motherboard. Failure in doing so will void the manu-
facturer warranty on your power supply and motherboard.
•
To provide adequate power to the add-on cards installed on the motherboard,
please connect the UIOP PWR connector to the power supply for these cards
to work properly.
Note: The Front Accessible VGA port (VGA2) is available on a 2U sys-
tem. However, when this VGA port (VGA2) is connected to a monitor, the
Backpanel VGA port (VGA1) will be disabled.
User's Manual
X8DTU-LN4F+ LED Indicators
State
Green: Blinking
Green: On
Blue: On (Windows OS),
Blinking (Linux)
2-6
Status
Normal
PWR On
Unit Identifi ed
