Motherboard Features
CPU
Memory
Chipset
Expansion
Slots
Graphics
Network
I/O Devices
•
®
Two Intel 5500/5600 Series (LGA 1366) processors;
each processor supports two full-width Intel Quick-
Path Interconnect (QPI) links with a total of up to 51.2
GT/s Data Transfer Rate (6.4 GT/s per direction)
•
18 240-pin, DDR3 1333/1066/800 MHz SDRAM
DIMM sockets in three-channel memory bus.
•
Support for up to 192 GB* of Registered ECC or 48
GB of Unbuffered ECC/Non-ECC DDR3 memory
(*Refer to Supermicro's Memory Recommendation
List posted at www.supermicro.com.)
DIMM sizes
•
UDIMM 1 GB, 2 GB, and 4GB
•
RDIMM 1 GB, 2GB, 4GB, 8GB, and 16 GB
•
Intel® 5520 Chipset (5520 IOH & ICH10R)
•
One (1) PCI Express 2.0 x16 slot (J2)
•
One (1) PCI Express2.0 x8 + x4 slot (J1)
•
One (1) PCI Express 2.0 x8 slot (J3)
•
Winbond BMC Video Controller (Matrox G200eW)
•
Two Intel 82576EB Gigabit (10/100/1000 Mb/s) Eth-
ernet Dual-Port Controller for LAN 1 - LAN 4 ports.
•
Single Realtek RTL8201N PHY to support IPMI_LAN
2.0 )
SATA Connections
•
SATA Ports
•
R A I D ( W i n -
dows)
•
RAID (Linux)
Integrated IPMI 2.0
•
IPMI 2.0 supported by the WPCM450 BMC
Keyboard/Mouse
•
PS/2 Keyboard/Mouse ports on the I/O backplane
Serial (COM) Ports
•
Two (2) Fast UART 16550 Connections: one 9-pin
RS-232 port and one header
Super I/O
•
Winbond Super I/O 83627DH
2-7
Chapter 2: Overview
Six (6)
RAID 0, 1, 5, 10
RAID 0, 1, 10
