RS232 Port 1
For a Modem connection or remote control of the unit. See section 3.13 for information about
configuring the modem settings in the menu system. See section 8 for RS232 Remote Control
Protocols.
DB-9 Pin Configuration For Port 1
Pin Use
1 DCD
2 RX
3 TX

1.8 Power-Up

It is important that the power-up procedures be followed carefully. The unit uses its auto-detect
feature to detect camera signals during power-up, and configure itself automatically.
Power-up procedure
Once the system installation is complete, apply
power in the following order:
1. Energize the monitors and all of the cameras.
2. Energize the DVMRe-4L.
Once power is applied to the unit, it will begin its power-up procedure. The unit will begin by displaying
the software version on Monitor-A, and then the unit will begin recording automatically.
Check Video Input Quality
Check the picture quality by selecting each camera for full screen display. If the picture quality is poor,
check the following items:
•
The BNC connections.
•
The loop-through terminations.
•
The video levels of incoming signals.
•
The possibility of ground loops.
•
Consult the camera's installation instructions for additional information about proper camera setup.
Check Record And Playback Quality
Record for at least three minutes at the default record
each camera for full screen display. Check the playback picture quality.
0150-0257A
Pin Use
4 DTR
5 Ground
6 Not Connected
11
Pin Use
7 RTS
8 CTS
9 Not Connected
Power Supply Input
Voltage: 12 Volt DC
Power: 60 Watt (5 Amp)
Connector: 2.1mm barrel, center positive
rate. Then play back the recording, selecting
1 5
6 9
DB-9 on back panel.
Kalatel DVMRe-4L
