Conditional Indicators
Condition
Alarm
Autolist™ Program
mode
Freeze
Motion Detection
Videoloss
Zoom
Status Display Box
A Status Display Box can be viewed by pressing the Camera Number button twice. Status Indicators
include:
On Live Fullscreen:
•
Archive Status: Not Connected. (This feature is not available on this model.)
•
Network: Displays all current Network connections. Normal connection is displayed as ip.ip or ---
if there is no connection. Live connections are displayed as E1: ip.ip, E2: ip.ip, etc. (where ip.ip
represents the last 2 bytes of the IP Address).
On Playback Fullscreen:
•
All the above, including Image Quality Setting: High, Medium, Standard.
0150-0257A
Full Screen Indicator
ALM
PGM
FRZ
M
VDL
ZOOM
20
Multiscreen Indicator
A in cameo of camera in alarm
PGM
(Asterisk) in frozen cameo
*
M in cameo w/ motion detection
V in cameo with videoloss
ZOOM
