4. Technical Specifications

4. Technical Specifications

4.1. Power Supply Specifications

Power
Supply Type
HI
HIP
24
24P
48
48P
a
Power consumption varies based on configuration.
b
(T) denotes time-delay fuse.
Table 4.1. Power Supply Specifications

4.2. Critical Alarm Relay Specifications

Table 4.2. Form C Contact Relay Specifications

4.3. Copper Ethernet Port Specifications

The RX1510 can be ordered with several different modules which contain 10/100Tx or
10/100/1000Tx Ethernet ports. All copper Ethernet ports have the following specifications:
Parameter
Speed
Duplex
Cable-Type
Wiring Standard
Max Distance
Connector
Isolation
Table 4.3. Copper Ethernet Port Specifications
RuggedCom® RuggedBackbone™
Input Range
Min Max
88 VDC 300 VDC
85 VAC 264 VAC
88 VDC 300 VDC
85 VAC 264 VAC
10 VDC 36 VDC
10 VDC 36 VDC
36 VDC 72 VDC
36 VDC 72 VDC
Voltage
30VDC
250VAC
10/100 or 10/100/1000 Mbps
Internal Max. Power
Fuse Rating Consumption
b
2A(T) 52W Max
b
2A(T) 52W Max
b
2A(T) 52W Max
b
2A(T) 52W Max
b
2A(T) 52W Max
b
2A(T) 52W Max
Specification
FDX / HDX
> Category 5
TIA/EIA T568A/B
100 m
RJ45
1.5kV
39 RX1510 Installation Guide Rev 104
Max Power
Connections
a
Output
Screw
42W
terminal block
Pluggable
42W
terminal block
Screw
42W
terminal block
Pluggable
42W
terminal block
Screw
42W
terminal block
Pluggable
42W
terminal block
Current
5A
6.25A
Notes
Auto-negotiating
Auto-negotiating
Shielded/Unshielded
Auto-Crossover, Auto-Polarity
RMS 1-minute
