3. Installation
3. Note the location of the SIM card cages. For modules W11 and W32, install the SIM card in
SIM 1. For module W22, install a SIM card in both SIM 1 and SIM 2.
4. Top open a SIM card cage, slide the silver catch down towards the antenna connector end
of the module and flip the cage open.
5. Hold the SIM card at its notched end, with its connectors facing down, and insert the SIM
card into the cage.
6. Flip the cage down and slide the silver catch up away from the antenna connector end of
the module.
7. Replace the back of the module and secure the back of the module with the four screws
removed earlier.
8. Re-install the module in the RX1510.
RuggedCom® RuggedBackbone™
33
RX1510 Installation Guide Rev 104
