Rainbow2 IP Phone User Manual

4.5.6 Tone

Set the ToneScript for each tone.
For example, MWI Dial Tone: 350@-19,440@-19;2(.1/,1/1=2);10(*/0/1+2)
Frequency1, Frequency2 ;Cadence Section1;Cadence Section2
350@-19: Frequency1 is 350HZ at -19dBm
440@-19: Frequency2 is 440HZ at -19dBm
2(.1/,1/1=2): Cadence Section length is 2s, 0.1s on, 0.1s off, with frequencies 1 and 2
10(*/0/1+2): Cadence Section length is 10s, always on(* means always, 0 means never), with
frequencies 1 and 2.
1. Country stands: select a country standard tone as default.
2. Dial Tone：Play when prompting the user to enter a phone number.
3. Outside Dial Tone：An alternative to Dial Tone usually used to prompt the user to enter an
external phone number (versus an internal extension). This is triggered by a "," character
encountered in the dial plan.
4. Busy Tone：Play when a 486 RSC is received for an outbound call.
5. Reorder Tone：Play when an outbound call has failed or after the far end hangs up during an
established call.
6. Off Hook Warning Tone: Play when user does not place the handset on the cradle properly.
7. Ring Back Tone：Play for an outbound call when the far end is ringing.
8. MWI Dial Tone：Play when there are unheard voicemails.
9. Holding Tone：Indicate to the local user that the far end has placed the call on hold.
10. Conference Tone：Play to all parties when a 3 way conference is in progress.
