Installation - ATCOM Rainbow2 User Manual

Rainbow2 IP Phone User Manual
line bracket Cable CD
Rainbow2 1 1 1 1 1pcs 1
1.5m
Note: Power adapter (Input: AC 100~240V, 50/60Hz; Output: 5V,1000mA;)

1.9 Installation

Connect LAN port to PC with Ethernet cable, or connect Rainbow2 to a switch/router which is in the
same network as your PC. It uses DHCP mode by default, and you can review its current IP address
by pressing key on idle state. To access the web interface, you can input the IP address in IE
browser. E.G. The IP address of your Rainbow2 is 192.168.1.100, you can input 192.168.1.100 and
press enter key on your browser to access its webpage. There are two login level:
User
Admin
No password is set for those two accounts with factory settings. You can click admin button on the
right corner of the webpage to switch from the user to admin mode. To set the password for user and
admin login you can firstly login as admin and enter the Network--->Advance page as following.
8
ATCOM TECHNOLOGY CO., LIMITED www.atcom.cn
