Rainbow2 IP Phone User Manual
3. User ID: Username of sip account.
4. Authenticate ID: normally is the same with User ID, can also leave it as blank.
5. Password: Password of SIP account.
6. SIP Server: SIP server address, support both IP address and domain name.
7. SIP Port: SIP server port , defaults to 5060.
8. SIP Redundancy Server: SIP redundancy server address.
9. Use Outbound Proxy: Whether to use outbound proxy.
10. Outbound Proxy Server：Outbound proxy server address. All signaling request will be send to
outbound proxy server firstly.
11. Outbound Proxy Port: Outbound proxy server port.
12. Register Expires: register expire time, defaults to 300 seconds.
13. Subscribe Expires: subscribe expire time, defaults to 3600 seconds.
14. Transport Type: UDP/TCP/TLS. Defaults to UDP.
15. SIP 100Rel Require: whether to enable 100Rel. If enabled, 100rel parameters will be added to
the SIP request to support PRACK.
16. Session Timer Enable：whether to enable Session Timer.
17. Early Update Enable：whether to enable Early Update.
18. Caller ID Display: whether to display Caller ID
19. AutoSubscribeMWIEnable：whether to enable SubscribeMWI
20. Server List：choose the server type.
21. DNS Mode: choose the DNS mode
22. BLF List URI: set BLF list URI when Rainbow2 cooperate with Broadworks.
Codec Configuration

1. Prefer Codec: Select a preferred codec for all calls. Defaults to G711u. Conversation will be set
ATCOM TECHNOLOGY CO., LIMITED www.atcom.cn
28
