5.2.2

Connection diameter and protection

Please gather the minimal dimensions from the following
table:
Type PROTECT
Diameter
Mains line
Loads connector
Protection
Mains fuse
Table 1: Connection diameter and protection
5.3

One phase mains connector

5.3.1

Preparation for the one phase mains connector

Before starting the connection tasks check that:
♦ the values of the mains voltage (input voltage) and
♦ the grounding connection complies with the IEC norms
♦ the UPS is connected to the mains via a separate and
♦ the prefuse or the power fuse in the NS distribution has
♦ the connection line from the prefuse to the UPS has to
C. 6000 (S)
6 mm
6 mm
32 A
frequency complies with the values on the label on the
UPS,
or with the regional regulations,
fused line in a preswitched NS distribution,
the same or higher value as indicated on the label on
the rear of the UPS appliance,
have a minimal diameter as defined in table 1:
„Connection diameter and protection"
The UPS carries high voltage. The unit may only
be installed or opened by trained and qualified
personnel. Repairs may only be carried out by
qualified customer service staff!
C. 10000 (S)
2
10 mm
2
10 mm
50 A
30
2
2
