3Com DOS
Diagnostics Program
1 Ensure that the EtherCD is in the CD-ROM drive.
2 At the DOS prompt, enter the following command:
3Com NIC
Diagnostics Program
1 Make sure that the NIC is installed and connected to the network and the driver
2 Click Start in the Windows taskbar.
3 Select Programs, and then 3Com NIC Utilities.
4 Click 3Com NIC Doctor.
Use the Windows-based 3Com NIC diagnostics program if you are running any of
the following operating systems:
Windows 98
Windows 95
Windows NT 4.0
NOTE: The following sections explain how to start both NIC diagnostics programs.
However, specific instructions are provided only for using the Windows-based

3Com NIC diagnostics program.

To start the 3Com DOS diagnostics program:
\3c990cfg.exe
NOTE: For PCs running Windows 2000 or Windows NT 3.51, do not run the DOS
diagnostics program from the MS-DOS box in Windows. Exit Windows, reboot
with a DOS-bootable diskette, and then run the program.
For more information about how to make a DOS-bootable diskette
Go to: Making a DOS-Bootable Diskette
For more information about the 3Com DOS Diagnostics program
Go to: 3Com DOS Configuration
To start the 3Com Windows-based NIC diagnostics program:
is installed.
The 3Com NIC Diagnostics General (tab) screen appears.
For more information about the 3Com NIC Diagnostics program
Go to: 3Com NIC Diagnostics

General Tab

Select the General tab to display the node address, I/O address, and device ID for
the installed NIC.
This screen also allows you to show or not show the 3Com icon in the Windows
system tray and enable Auto Echo, which sets the PC to respond automatically to
requests from other PCs that run the Remote Wake-Up test.
Configuration Tab
Select the Configuration tab to view and modify configuration settings for the
installed NIC.
Running Diagnostics Programs
.
Program.
Program.
57
