5.2.

Server Side Connection Descriptors

Section Title
Connections
Column Title
Specify which port the device is connected
Port
to the FieldServer
Baud* Specify baud rate
Parity* Specify parity
Data_Bits*
Specify data bits
Stop_Bits*
Specify stop bits
Protocol
Specify protocol used
Handshaking* Specify hardware handshaking
Example
Server Side Connections
//
Connections
Port,
P1,
5.3.

Server Side Node Descriptors

Section Title
Nodes
Column
Title
Node_Name Provide name for Node
Generic Node ID unique to port. Also used as panel
Node_ID
number.
Protocol Specify protocol used
Port Port to which node belongs
Example
// Server Side Nodes
Nodes
Node_Name,
Node_1,
2
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
