Appendix A.3.
When the panel powers up or is restarted it will send an event on zone/circuit 69 device 0.
When the panel is reset from the Hot Keys on the front panel, it will send an event on zone/circuit 90,
device 9.
The Client driver will clear all the Secutron_Type=device and Secutron_Type=function Data Arrays
when it traps any of these 2 events, provided the circuit 69 and 90 Map Descriptors have been set up
as per the example Map Descriptors under the Client Side configuration instructions.
Other events for Circuits 69 and 90 are shown below for which a bit will be set in the
Secutron_Type=device Map Descriptor's Data Array at the device offset values shown below:
Circuit
Program Restart
(Circuit 69)
Hot Key Activation
(Circuit 90)
Function number of the Hot Key
pressed.
Appendix A.4.
The Client driver will report all events it receives from the panel on the RuiNet F screen.
If an event is received that has no corresponding Map Descriptor defined, this will be reported on the
RuiNet E screen. This is a useful configuration tool to ensure that all required data is stored.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2269 Toll Free: 888-509-1970 email: support@fieldserver.com
Panel Power-up, Restarts and Resets
000 – Power On/Hard reboot
001 - Watchdog
002 – Clock Monitor
001 – Fire Drill
002 - Lamp Test
003 – Releaser Disconnect
004 – Relay disconnect
005 – Test mode
006 – Signal Disconnect
007 - Acknowledge
008 – Signal Silence
009 - Reset
010 – Common Disconnect
011 – General Alarm
012 - Halt
013 - Abort
nd
013 – 2
016 – Switch 1 On
017 – Switch 2 On
018 – Switch 3 On
019 – Switch 4 On
020 – Switch 5 On
021 – Switch 6 On
022– Switch 7 On
023– Switch 8 On
024– Switch 9 On
025– Switch 10 On
Driver Messages, Error Messages and Optional Map Descriptors
Events
Stage Inhibit
Page 14 of 15
003 – Illegal Instruction
004 – Unused Interrupt
005 – Orphan Interrupt
026– Switch 11 On
027 – Switch 12 On
028 – Switch 13 On
029 – Switch 14 On
030 – Switch 15 On
031 – Switch16 On
032 – Switch 1 Off
033 – Switch 2 Off
034 – Switch 3 Off
035 – Switch 4 Off
036 – Switch 5 Off
037 – Switch 6 Off
038– Switch 7 Off
039– Switch 8 Off
040– Switch 9 Off
041– Switch 10 Off
042– Switch 11 Off
043 – Switch 12 Off
044 – Switch 13 Off
045 – Switch 14 Off
046 – Switch 15 Off
047 – Switch16 Off
051 – Manual Restart
